As PCB technology has continued to evolve, it has paved the way for the creation of a host of exciting product innovations. A prime example is the development of the PCB for LED lighting. The LED is soldered to the circuit board and features a chip that produces the light when electrically connected. A thermal heat sink and a ceramic base are used to bond the chip.
A LED PCB board tends to generate a high volume of heat, making it difficult to cool via traditional means. Consequently, metal core PCBs are frequently chosen for LED application due to their enhanced ability to dissipate heat. Aluminum in particular is often used to manufacture printed circuit boards for LED lights. The aluminum PCB typically includes a thin layer of thermally conductive dielectric material that can transfer and dissipate the heat with much greater efficiency than a traditional rigid PCB.
LED PCB Applications
LED PCB lights can be incorporated into numerous lighting applications due to their combination of excellent energy efficiency, low cost and maximum design flexibility. Examples include Automotive headlights, Airport runway landing lights, Lighting used in military field applications, Street lighting, Highway tunnel lighting, Photovoltaic (solar) lighting, Flashlights and lanterns, Traffic and signal lighting, Lighting in hospital operating rooms, High growth plant lighting and many others.
Shanxu PCB Provides Effective, Affordable PCB LED Lighting Solutions
As a full feature PCB solutions provider with more than a decade of experience, we're capable to provide LED PCB fabrication, components procurement and assembly all under one roof. We can work with you to develop metal core/aluminum circuit boards customized to your specific applications. We feature competitively priced PCBs made with standard FR-4 material that includes a thermal aluminum clad layer that will efficiently dissipate heat, keep all LED PCB components cool and significantly enhance the performance of your products.
Thermal conductivity in lighting:
Thermal conductivity may be essential to dissipate heat on led boards.
Standard FR4 material has the lowest thermal conductivity with about around 0,3W/MK.
Standard CEM3 material thermal conductivity usually is higher than average FR4 material thermal conductivity. However, there is also unique CEM-3 material with an even higher thermal conductivity as 1,0-1,2W/MK (typically, CEM-3 material has lower flexural strength than FR4 and thermal expansion greater than FR4, so CEM-3 has lower mechanical endurance compared to FR4).
Standard aluminum material thermal conductivity usually is higher than typical FR4 and average CEM-3 thermal conductivity, about 1,0-2,2W/MK (or even higher).
